CNC routers/

CNC router

Dimension
3100*1850*1650
Platform size
1300*2500
Working area
1220*2440*200
Travelling speed
20m/min(MAX)
Working speed
12m/min(MAX)
Working voltage
AC220V(Optional 380V)
Spindle power
Water cooled 3.2KW-24000RPM
Device architecture
One molding process,space saving cabinet (380V for the normal external cabinet)high structural stability ,high precision and small
deformation
Driving system
XYZ: 86 high torque stepper drive motor and drive
Rack and pinion
The new 1.2m alloy hardened helical gear rack + alloy hardened helical gear rack
Guide Rails
Taiwan Original 20 guide rails +Taiwan TBI 2510 ball screw
Operating system
Weihong
Platform structure
Aluminum profile + fixture
Electrical accessories
Omron, Chint
Inverter
Best
Power cable
Shanghai customized high-soft high-speed shielding cable,
anti-interference and anti-breakage
Lubrication system
Oil pump centralized lubrication control
Security system
Overtravel protection, electrical protection etc.
Dust collector
2.2KW vacuum cleaner,Vacuum pipe,Vacuum hood
Fastenings
The transmission parts are fixed with high strength 12.9 class screws,
and the sheet metal is fixed with 304 stainless steel screws
Accuracy
Each axis is fixed rigidly, and the locating pin is added
to the precision part
Quality Control
Incoming material, process, delivery full control,
24 hours machine test

  • Product Details
  • Package and shipping
  • FAQs
  • Samples
  • Inquiry

CNC routerDescription:

A CNC wood router is an automatic computer-controlled machine tool for smart 2D, 2.5D, and 3D cutting, milling, carving, drilling, and grooving on popular woodworking plans, including wood arts & crafts, signs making, cabinets making, door making, gifts, modeling, decorations, wardrobe, and more furniture making projects & ideas. Such a machine tool kit consists of bed frame, spindles, vacuum table or T-slot table, controller, operating system, software, gantry, driver, motor, vacuum pump, guide rail, pinion, rack, ball screw, collet, limit switch, power supply, and some additional parts & accessories.

Advantages:

1.Ball screw for Z axis .It’s stable running,precision and fast.
2.X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.
3.The whole machine adopts robust structure, powerful spindle motor, precise and efficient DSP control system, just need the
handle to operate the machine,easy and convenient.
4.Heavy duty frame and gantry,it’s very strong and stability.
Shipping:
We cooperate with forwarders experienced in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries.

1. This is the first time I buy the machine, is it easy to operate?
A: We can provide the operation manual or video for guiding. If it is hard for you learning, we can also help you by “Team-viewer” online, with telephone or Skype explain.
2. ARE YOU TRADING COMPANY OR MANUFACTURER ?
A: We are factory.
3. Can I visit your factory?
A: Yes! We greatly welcome customers to visit our factory!
4. What is your MOQ?
A: Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.
